25 x heavy transport Samms 6-axle flat railcar for military tank transport or others.

Six-wheeled bogie flat wagon with stanchions, end flaps, and folding loading sills, but without side flaps. This wagon is primarily intended for transporting slabs.

he wagon is used with folded-out bolsters for transporting heavy rolled steel sections and other bulky goods. The supports for loading and unloading have been discontinued. The wagon bridge is a welded frame structure with main components made of St 52. The main loads are absorbed by the outer solebars made of IPE 550. The buffer beams are designed in such a way that the automatic coupler can be installed later without major modifications. The floor is made of pine planks measuring 70 x 180 mm; it can take a wheel load of 5.0 t. There are six split, folding bolsters built into the floor. The vehicle has six removable stanchions on each long side and two retractable (fold-down) stanchions on each end face. The drop ends can be folded down. When not in use, the removable stanchions are stored in pockets on the side solebars. The lowered fold-down stanchions are still within the loading gauge so the wagon can also be driven with the fold-down stanchions lowered and the drop ends folded down. The ground-operated parking brake only acts on one bogie. The wagon has a non-continuous draw gear and high-performance buffers.

Technical details
Loading length (mm) 15,000
Loading width (mm) 2,560
Loading height (mm) 1,200
Loading area (m2) 45.7
Average tare weight (kg) 31,000
Maximum speed (km/h) 120
International usability RIV
Smallest radius of curvature (m) 80
With parking brake

Brake type KE-GP
Number of brake cylinders (pcs.) 2
Brake cylinder diameter (mm) 355
Type of load-proportional braking
Two-stage, mechanical, to be changed over manually
Buffer type: end force (kN) 590

Buffer type: stroke (mm) 105
Buffer head dimensions (mm) Avg 450
Automatic coupler Prepared
Removable wagon accessories
12 removable stanchions made of I sections
Distributor valve type KE 1adSL

The cars need a new overhaul and refurbishment. but they are ready to roll out to workshop.
The Abrams tank is no part of this deal! 🙂

We look forward to your inquiry.
